Friday, March 24, 2017

This is what phylodiversity looks like

Following on from earlier posts exploring how to map DNA barcodes and putting barcodes into GBIF it's time to think about taking advantage of what makes barcodes different from typical occurrence data. At present GBIF displays data as dots on a map (as do I in http://iphylo.org/~rpage/bold-map/). But barcodes come with a lot more information than that. I'm interested in exploring how we might measure and visualise biodiversity using just sequences.

Based on a talk by Zachary Tong (Going Organic - Genomic sequencing in Elasticsearch) I've started to play with n-gram searches on DNA barcodes using Elasticsearch, an open source search engine. The idea is that we break the DNA sequence into every possible "word" of length n (also called a k-mer or k-tuple, where k = n).

For example, for n = 5, the sequence GTATCGGTAACGAACTT would look like this:

GTATCGGTAACGAACTT

GTATC
 TATCG
  ATCGG
   TCGGT
    CGGTA
     GGTAA
      GTAAC
       TAACG
        AACGAA
         ACGAAC
          CGAACT
           GAACTT

The sequence GTATCGGTAACGAACTT comes from Hajibabaei and Singer (2009) who discussed "Googling" DNA sequences using search engines (see also Kuksa and Pavlovic, 2009). If we index sequences in this way then we can do BLAST-like searches very quickly using Elasticsearch. This means it's feasible to take a DNA barcode and ask "what sequences look like this?" and return an answer qucikly enoigh for a user not to get bored waiting.

Another nice feature of Elasticsearch is that it supports geospatial queries, so we can ask for, say, all the barcodes in a particular region. Having got such a list, what we really want is not a list of sequences but a phylogenetic tree. Traditionally this can be a time consuming operation, we have to take the sequences, align them, then input that alignment into a tree building algorithm. Or do we?

There's growing interest in "alignment-free" phylogenetics, a phrase I'd heard but not really followed up. Yang and Zhang (2008) described an approach where every sequences is encoded as a vector of all possible k-tuples. For DNA sequences k = 5 there are 45 = 1024 possible combinations of the bases A, C, G, and T, so a sequence is represented as a vector with 1024 elements, each one is the frequency of the corresponding 5-tuple. The "distance" between two sequences is the mathematical distance between these vectors for the two sequences. Hence we no longer need to align the sequences being comapred, we simply chunk them into all "words" of 5 bases in length, and compare the frequencies of the 1024 different possible "words".

In their study Yang and Zhang (2008) found that:

We compared tuples of different sizes and found that tuple size 5 combines both performance speed and accuracy; tuples of shorter lengths contain less information and include more randomness; tuples of longer lengths contain more information and less random- ness, but the vector size expands exponentially and gets too large and computationally inefficient.

So we can use the same word size for both Elasticsearch indexing and for computing the distance matrix. We still need to create a tree, for which we could use something quick like neighbour-joining (NJ). This method is sufficiently quick to be available in Javascript and hence can be computed by a web browser (e.g., biosustain/neighbor-joining).

Putting this all together, I've built a rough-and-ready demo that takes some DNA barcodes, puts them on a map, then enables you to draw a box on a map and the demo will retrieve the DNA barcodes in that area, compute a distance matrix using 5-tuples, then build a NJ tree, all on the fly in your web browser.

This is all very crude, and I need to explore scalability (at the moment I limit the results to the first 200 DNA sequences found), but it's encouraging. I like the idea that, in principle, we could go to any part of the globe, ask "what's there?" and get back a phylogenetic tree for the DNA barcodes in that area.

This also means that we could start exploring phylogenetic diversity using DNA barcodes, as Faith & Baker (2006) wanted a decade ago:

...PD has been advocated as a way to make the best-possible use of the wealth of new data expected from large-scale DNA “barcoding” programs. This prospect raises interesting bio-informatics issues (discussed below), including how to link multiple sources of evidence for phylogenetic inference, and how to create a web-based linking of PD assessments to the barcode–of-life database (BoLD).

The phylogenetic diversity of an area is essentially the length of the tree of DNA barcodes, so if we build a tree we have a measure of diversity. Note that this contrasts with other approaches, such as Miraldo et al.'s "An Anthropocene map of genetic diversity" which measured genetic diversity within species but not between (!).

Practical issues

There are a bunch of practical issues to work through, such as how scalable it is to compute phylogenies using Javascript on the fly. For example, could we do something like generate a one degree by one degree grid of the Earth, take all the barcodes in each cell and compute a phylogeny for each cell? Could we do this in CouchDB? What about sampling, should we be taking a finite, random sample of sequences so that we try and avoid sampling bias?

There are also data management issues. I'm exploring downloading DNA barcodes, creating a Darwin Core Archive file using the Global Genome Biodiversity Network (GGBN) data standard, then converting the Darwin Core Archive into JSON and sending that to Elasticsearch. The reason for the intermediate step of creating the archive is so that we can edit the data, add missing geospatial informations, etc. I envisage having a set of archives, hosted say on GitHub. These archives could also be directly imported into GBIF, ready for the time that GBIF can handle genomic data.

References

  • Faith, D. P., & Baker, A. M. (2006). Phylogenetic diversity (PD) and biodiversity conservation: some bioinformatics challenges. Evol Bioinform Online. 2006; 2: 121–128. PMC2674678
  • Hajibabaei, M., & Singer, G. A. (2009). Googling DNA sequences on the World Wide Web. BMC Bioinformatics. Springer Nature. https://doi.org/10.1186/1471-2105-10-s14-s4
  • Kuksa, P., & Pavlovic, V. (2009). Efficient alignment-free DNA barcode analytics. BMC Bioinformatics. Springer Nature. https://doi.org/10.1186/1471-2105-10-s14-s9
  • Miraldo, A., Li, S., Borregaard, M. K., Florez-Rodriguez, A., Gopalakrishnan, S., Rizvanovic, M., … Nogues-Bravo, D. (2016, September 29). An Anthropocene map of genetic diversity. Science. American Association for the Advancement of Science (AAAS). https://doi.org/10.1126/science.aaf4381
  • Yang, K., & Zhang, L. (2008, January 10). Performance comparison between k-tuple distance and four model-based distances in phylogenetic tree reconstruction. Nucleic Acids Research. Oxford University Press (OUP). https://doi.org/10.1093/nar/gkn075

Notes for WikiCite 2017: Wikispecies reference parsing

Wikispecies logo svg In preparation for WikiCite 2017 I'm looking more closely at extracting bibliographic information from Wikispecies. The WikiCite project "is a proposal to build a bibliographic database in Wikidata to serve all Wikimedia projects". One reason for doing this is so that each factual statement in WikiData can be linked to evidence for that statement. Practical efforts towards this goal include tools to add details of articles from CrossRef and PubMed straight into Wikidata, and tools to extract citations from Wikipedia (as these are likely to be sources of evidence for statements made in Wikipedia articles).

Wikispecies occupies a rather isoldated spot in the Wiikipedia landscape. Unlike other sites which are essentially comprehensive encyclopedias in different languages, Wikispecies focusses on one domain - taxonomy. In a sense, it's a prototype of Wikidata in that it provides basic facts (who described what species when, and what is the classification of those species) that in principle can be reused by any of the other wikis. However, in practice this doesn't seem to have happened much.

What Wikispecies has become, however, is a crowd-sourced database of the taxonomic literture. For someone like me who is desparately gathering up bibliographic data so that I can extract articles from the Biodiversity Heritage Library (BHL), this is a potential goldmine. But, there's a catch. Unlike, say, the English language Wikipedia which has a single widely-used template for describing a publication, Wikispecies has it's own method of representing articles. It uses a somewhat confusing mix of templates for author names, and then uses barely standardised formatting rules to mark out parts of a publication (such as journal, volume, issue, etc.). Instead of a single template to describe a publication, in Wikispecies a publication my itself be described by a unique template. This has some advantages, in that the same reference can be transcluded into multiple articles (in other words, you enter the bibliographic details once). But this leaves us with many individual templates with multiple, idiosyncratic styles of representing bibliographic data. Some have tried to get the Wikispecies community to adopt the same template as Wikipedia (see e.g., this discussion) but this proposal has met with a lot of resistance. From my perspective as a potential consumer of data, the current situation in Wikispecies is frustrating, but the reality is that the people who create the content get to decide how they structure that content. And understandably, they are less than impressed by requests that might help others (such as data miners) at the expense of making their own work more difficult.

In summary, if I want to make use of Wikispecies I am going to need to develop a set of parsers than can make a reasonable fist of parsing all the myriad citation formats used in Wikispecies (my first attempts are on GitHub). I'm looking at parsing the references and converting them to a more standard format in JSON (I've made some notes on various bibliographic formats in JSON such as BibJSON and CSL-JSON). One outcome of this work will be, I hope, more articles discovered in BHL and hence added to BioStor), and more links to identifiers, which could be fed back into Wikispecies. I also want to explore linking the authors of these papers to identifiers, as already sketched out in The Biodiversity Heritage Library meets Wikidata via Wikispecies: adding author identifiers to BioStor.

Wednesday, February 15, 2017

New feature for BioStor: extracting literature cited from OCR text

At present BioStor provides a simple display of an article extracted from BHL. You get the page images, and sometimes a map and an altmetric "donut". But we can do better than this. For example, I'm starting to experiment with displaying a list of literature cited by the article. Below is a screenshot of the article A remarkable new species of Homalomena (Araceae) from Peninsular Malaysia showing the two references this article cites:

Screenshot 2017 02 15 19 28 17

These references have been extracted using some simple regular expressions written in Javascript and wrapped up in a CouchDB view. They are extracted as simple text strings, I've not made any further attempt to parse the string into authors, title, journal, etc.

Of course, what we really want is to be able to convert these strings into clickable links to the actual reference. In the spirit of "We don't need no stinkin' parser" (see also Resolving free-form citations) I've added a little search icon that when you click on it attempts to find the reference in BioStor. In the screenshot above we've found both references in BioStor.

Obvious next steps are to add other resolvers (such as CrossRef for DOIs), do the resolution before the references are displayed (rather than wait for the user to click on the search icon), and even more usefully, display a list of articles that cite each article in BioStor (in the example above, both cited articles should "know" that they have been cited).

Whether an article in BioStor has a list of citations depends on the success of the regular expressions in extracting them, and whether the database has the OCR text. The current version of BioStor didn't originally store the OCR text, so I'm slowly adding that to the references. Other examples of articles with citations include Northeast African racers of the Platyceps rhodorachis complex (Reptilia: Squamata: Colubrinae) and Synopsis of the Neotropical mantid genus Pseudacanthops Saussure, 1870, with the description of three new species (Mantodea: Acanthopidae).

Long term adding linked citations to BioStor means we get a step closer to being able to offer readers an experience like PubMed Central (PMC), where articles in PMC are linked to articles in PMC that either cite, or a cited by that article. I think there's a case for a PubMed Central-like service for biodiversity literature (see Possible project: A PubMed Central for taxonomy) that rescues that literature from the ghetto much of it currently resides in, and instead makes it a first class citizen of the wider digital biodiversity landscape.

Saturday, January 14, 2017

Displaying taxonomic classifications from Wikidata using d3js and SPARQL

Sahelanthropus tchadensis TM 266 01 060 1 Following on from previous posts The Semantic Web made fun: d3sparql and The Biodiversity Heritage Library meets Wikidata via Wikispecies: adding author identifiers to BioStor I've put together an example query that can be used to extract a taxonomic classification from Wikidata. The query is inspired by the http://biohackathon.org/d3sparql/ example, and uses the wikidata property P171 ("parent taxon") which is subproperty of rdfs:subClassOf (the property used in the d3sparql example which queries the Uniprot taxonomy).

The following SPARQL query generates a list of nodes in the tree representing the classification of Hominini (humans, chimps, and their extinct relatives):

PREFIX wdt: <http://www.wikidata.org/prop/direct/>
PREFIX wd: <http://www.wikidata.org/entity/>
SELECT ?root_name ?parent_name ?child_name WHERE
{
 VALUES ?root_name {"Hominini"}
 ?root wdt:P225 ?root_name .
 ?child wdt:P171+ ?root .
 ?child wdt:P171 ?parent .
 ?child wdt:P225 ?child_name .
 ?parent wdt:P225 ?parent_name .
}

Using https://query.wikidata.org/sparql as the endpoint, in http://biohackathon.org/d3sparql/ this generates the following diagram:

Screenshot 2017 01 14 11 41 55

There are some obvious issues with this classification, such as genera that lack descendant species (e.g., Cyphanthropus). Indeed, we could imagine developing SPARQL queries to flag up such errors (see A use case for RDF in taxonomy). But the availability and accessibility of Wikidata and its SPARQL interface makes it a great playground to explore the utility of SPARQL for exploring taxonomic data.

Wednesday, January 11, 2017

The Biodiversity Heritage Library meets Wikidata via Wikispecies: adding author identifiers to BioStor

I've added an experimental feature to BioStor that uses data from Wikidata and Wikispecies to augment what information BioStor displays on authors. This is a crude first step towards the goal of representing all the data in BioStor as a "knowledge graph" where articles, journals, and authors are all treated as entities, all have identifiers, and we can explore relationships between those entities (e.g., citation, co-authorship, etc.). At the moment this is true of articles, which have Biostor URLs (and in many cases DOIs), and for most journals which are identified by their ISSN. Using identifiers helps reduce ambiguity, especially if there are multiple ways to represent the same thing (e.g., all the alternative ways to write a journal name can be circumvented by using the journal's ISSN).

However, BioStor doesn't have a way to identify authors beyond simply searching for a name. As a first step to tackling this problem I've added a little widget that displays information about an author based on the name you are searching for. For example, searching for George Albert Boulenger will give you a list of publications where the author name is "George Albert Boulenger", as well as a picture of the author and some identifiers (from sources such as VIAF, ISNI, IPNI, and Wikidata):

Screenshot 2017 01 11 16 30 57

For now this widget is independent of the data in BioStor. I don't link an article to its author(s) using identifiers for those authors, nor have I tackled the problem of clustering all the variations in people's names together into one set of names that share the same identifier (see Equivalent author names) nor do I attempt to match names to identifiers (see Reconciling author names using Open Refine and VIAF) other than by an exact text search (for details see below). At this stage I just want to get a sense of what identifiers exist for an author, and what I can learn from those identifiers. I also want to explore the potential of Wikispecies as a source of data on people and publications, and how this relates to Wikidata (for earlier thoughts on using Wikipedia for the same goal see Thoughts on Wikipedia, Wikidata, and the Biodiversity Heritage Library).

Wikispecies

I confess I've never really "got" Wikispecies (e.g., Wikispecies is not a database), it seems to exist in isolation from Wikipedia, which is arguably more informative about many species. But there are a couple of things Wikispecies does very well. Firstly, it is building a rich, crowd-sourced bibliography of papers on the taxonomy of many different species. Readers of iPhylo will recall how many times I've expressed frustration at the nearly evidence-free nature of many online taxonomic databases that simply have lists of names unconnected to the primary literature. Many Wikispecies pages have long lists of papers, making it a potential goldmine. Recently there is a lot of interest in extracting bibliographic data from Wikipedia (see WikiCite). Wikispecies could also be harvested, although a major obstacle any such project faces is the lack of a consistent format for references in Wikispecies.

The other nice thing about Wikipecies is that it has articles on taxonomic authorities, and these often list publications by those authors, and also list external identifiers for those authors, such as the VIAF and ISNI identifiers used in the library world, IPNI and ZooBank identifiers used in taxonomic databases, and ORCID which is becoming the de-facto identifier for academic researchers. This information also ends up in Wikidata.

Using Wikidata to glue things together

Wikidata is an interesting project that, like Wikispecies, I've been in two minds about (see Wikidata, Wikipedia, and #wikisci). However, I've started to make more use of it recently. Inspired by the Wikidata:SPARQL query service/2016 SPARQL Workshop I decided to explore the SPARQL query interface to Wikidata. I was struck by one of the example queries involving Wikispecies, and so after a little bit of messing about came up with a query that takes the name of an author and returns some identifiers from Wikidata, as well as an image of that person if one is available. I restrict the results to people that have an article about them in Wikispecies, because I want start exploring using those articles to make assertions about authorship. Here is a query to search for "George Albert Boulenger":

SELECT *
WHERE
{
  ?item rdfs:label "George Albert Boulenger"@en .
  ?article schema:about ?item .
  ?article schema:isPartOf  .
  OPTIONAL {
   ?item wdt:P213 ?isni .
	}
  OPTIONAL {
   ?item wdt:P214 ?viaf .
	}
  OPTIONAL {
   ?item wdt:P18 ?image .
	}
  OPTIONAL {
   ?item wdt:P496 ?orcid .
	}
  OPTIONAL {
   ?item wdt:P586 ?ipni .
	}
  OPTIONAL {
   ?item wdt:P2006 ?zoobank .
	}
}

This query simply asks whether Wikidata has an item on this person, whether that item is linked to Wikispecies, what identifiers Wikidata has, and whether there is an image of the person. You can see the query "live" here:

I've added some code to BioStor to do this query on the fly, and display the results. So, for Boulenger we get: Screenshot 2017 01 11 17 04 16 Here is the result for noted carcinologist Jocelyn Crane who currently lacks identifiers: Screenshot 2017 01 11 17 05 32 A nice surprise was Bernard Landry: Screenshot 2017 01 11 17 07 14 Note the ORCID 0000-0002-6005-1067. Interestingly, Bernard Landry's ORCID profile doesn't list any publications, whereas we can see lists of these in BioStor and Wikispecies.

Where next?

There are several obstacles to mapping the names of authors to identifiers. One is simply the lack of identifiers. This seems to be rapidly becoming less of a problem with the efforts of the library community around VIAF, the rise of ORCID for living researchers, and the creation of Wikidata items for every taxonomist in Wikispecies. The next challenge is clustering the different ways of writing the same person's name into sets that represent the same person. As discussed above, there are tools for this. Furthermore, with Wikipedia and Wikispecies we have sources of lists of publications linked to a person and their identifiers, which should simplify the task considerably. What is nice about this is that it relies on a crowd-sourcing effort which is already well-established, namely those people who in adding articles to Wikispecies and Wikipedia are created a curated database of publications linked to authors. In many cases those publications are linked to BHL (the source that BioStor extracts its articles from), so many of the links between publications and people are essentially lying there, just waiting for some skilful harvesting.
